Description
Genzler Amplification announces the addition of a new innovative Bass Array 15-3 bass cabinet design. This slanted 15″ version of the BA concept further expands the Bass Array offerings with a powerful, big output, compact, cabinet design.
An excellent choice when used as a single enclosure or in combination with additional BA straight or slant cabinets. This offers multiple options to the player to configure their BA15-3 SLT stack for the best coverage of the stage or performance venue. The innovative Bass Array design blends the benefits of a 15” neodymium woofer in vented bass reflex design with the performance and pattern control of a 4 x 3” neodymium cone-driver line array element. The benefits of combining both loudspeaker platforms in an extremely compact speaker system are exponential for the player:
-Full, deep, low frequency response from the high efficiency 15” ported woofer.
-Smooth, seamless, clear and articulate mid-range to high frequency transition across the audio spectrum.
-Broad horizontal dispersion far exceeding conventional woofer/tweeter combinations.
The new BA15-3 SLT model utilizes a 6-degree slanted baffle providing increased projection towards the player and the audience. This unique cabinet shape also further reduces internal standing waves, which translates into an even clearer tonal experience.
Overview
-Power Handling: 400 Watts
-Impedance: 8 Ohms
-Speakers: 1-15" Faital neodymium 15″ cast frame, 4-3" Faital neodymium mid/high cone drivers
-Dimensions: 23" x 19.5" x 17.5"
-Weight: 35 lbs
Features
-Frequency Response 30-15KHz
-Sensitivity 1W/1M: 99 dB
-2 Speakon NL-2 connectors & 1/4" sealed jacks to reduce rear cabinet air loss and noise
-Heavy-duty textured black vinyl
-Black metal corners and side-mounted recessed handles
-Custom, curved grille with a unique center “pleat” to protect the array column
-Large rubber feet
